COMPUTING PLATFORM - CompactPCI / PXI Platforms

cPCIS-2632
3U CompactPCI Sub-system with 8-slot Backplane and 1+1 CompactPCI Redundant Power Modules

Features:

3U CompactPCI backplane with 7 peripheral card slots and 1 system slot

Temperature, voltage, and fan monitoring LEDs

Supports current sharing on +5V, +3.3V, and +12V

1+1 hot swappable 250W+250W CompactPCI Power supplies

PICMG 2.11 47-pin power interface

Hot-swappable cooling fans & filter

Supports rear I/O backplane with P2 connector (cPCIS-2632R)

Note: EMC blank panels (cPCI-Panel-Kit-3U1S) are optional. All models above do not include any system or peripheral board.

Ordering Information

cPCIS-2632

3U CompactPCI Sub-system with 8-slot Backplane and 1+1 CompactPCI Redundant Power Modules
