PCM-9112+
PC/104-Plus 16-CH 12-Bit 110kS/s Multi-Function DAQ Module

Features: PC/104-Plus specifications Rev. 1.2 compliant 12-bit A/D resolution Up to 110 kS/s sampling rate 16-CH single-ended or 8-CH differential inputs On-board A/D FIFO Bipolar or unipolar analog input ranges Programmable gains of x0.5, x1, x2, x4, x8 Automatic analog inputs scanning

Introduction

ADLINK PCM-9112+ is a 16-CH, 12-bit, 110 kS/s multi-function DAQ module for PC/104-Plus form factor. The PCM-9112+ module features flexible configurations on analog inputs. It provides analog inputs with 4 programmable input ranges for both bipolar and unipolar inputs. The A/D on the PCM-9112+ module features a sampling rate of up to 110kS/s with resolution at 12 bits. The module supports automatic analog input scanning, and offers a differential mode for 8-CH analog inputs and maximum noise elimination, as well as single-ended modes for 16-CH analog inputs.

Ordering Information

Associated Software

Download Area:

click on arrow  to download	Driver	Utility	BIOS	Associated Software	Manual	Datasheet
