Picolo
Tetra
Real time 4-CH
video capture card
Introduction
The Picolo Tetra is ADLINK's new video capture card allowing real-time image sequencing in parallel. The Picolo Tetra supports standard composite video acquisition in color (PAL, NTSC) or in monochrome format (CCIR, EIA). With high-quality hardware scaler, the Picolo series can acquire images in any format. Arbitrary cropping to regions of interest is built-in. The Picolo generates bitmaps in all popular color formats such as RGB, YUV, planar or packed. The Picolo series video capture boards are designed to drastically simplify the design of video surveillance applications. System integrators benefit from robust and easy-to-use standard connectors. TTL I/O lines are provided for simple system integration. In addition, the Picolo Tetra is compatible with MIO modules, enabling system integrators to implement isolated inputs and outputs.
Features:
- Four color video digitizers operating in parallel
- Up to 240fps in 64-bit, 66MHz PCI bus
- Color PAL / NTSC, monochrome CCIR / EIA camera support
- 4 buffered video outputs
- MIO, I/O module compatible
Ordering Information
|
Picolo Tetra |
Real time 4-CH video capture card |
Download Area:
|
|
Driver | Utility | BIOS | Others | Manual | Datasheet |
 |
|
