DAQ MTLB
Data Acquisition Toolbox
Adapter for Adlink Data Acquisition Cards
The ADLINK DAQ-MTLB for MATLAB®,
designed to integrate its hardwares with MATLAB® Data Acquisition
Toolbox. This tool enables users to directly control a wide range of
ADLINK data acquisition cards from MATLAB® environment. MATLAB®
users now can extend their data acquisition capability with almost
one hundred of ADLINK cards in a variety of form factors, including
PCI ExpressR, PCI, CompactPCI and PXI. Moreover, ADLINK is now one
of the twelve MathWorks Connections Program partners, and the only
supplier offering MATLAB® adaptor for high-speed digitizer up to
sampling rate of 130MHz with resolution of 14 bit. Users can now
measure and analyze live MHz signals from MATLAB® by combining
ADLINK hardware with MATLAB®, as well as generate arbitrary
waveforms. The ADLINK DAQ-MTLB for MATLAB® Toolbox supports complete
hardware trigger capability to perform an exact data acquisition
process and provides a consistent interface for ADLINK's data
acquisition cards allowing users to acquire, analyze, and visualize
data in an integrated MATLAB® environment.
Features
-
MATLAB® Data Acquisition Toolbox-compliant (Version 2.2 or higher)
-
Real-time data access and measurement directly in MATLAB® environment
-
Capable of 100 kS/s to 65 MS/s, 12-bit to 16-bit data acquisition
-
Supports a full range of ADLINK data acquisition cards. ( Supports a full range of ADLINK data acquisition cards. Check supported hardware )
-
Provides complete hardware trigger capability
-
Supports analog input, analog output, and digital I/O
Benefits
As DAQ-MTLB for
MATLAB® seamlessly interfaces with ADLINK data acquisition cards, it
enables fast and efficient access and manipulation of real-time data
for MATLAB® run-time analysis and visualization. For experienced DAQ
Toolbox users, all available commands can be leveraged to program
supported ADLINK cards. For novice DAQ Toolbox users, programming
samples and a user's guide are included in the DAQ-MTLB for MATLAB®
package to clearly describe all DAQ Toolbox commands. Since ADLINK
DAQ-MTLB for MATLAB® supports a comprehensive line of ADLINK data
acquisition products, users can enjoy greater flexibility and a
wider range of data acquisition parameters, from 12-bit to 16-bit
resolution, 100 kS/s to 65 MS/s sampling rate. DAQ-MTLB for MATLAB®
offers a powerful and versatile support when developing measurement
and analysis systems based on MATLAB®.
System requirements
Operating System :
-
Microsoft® Windows® 2000 Professional
-
Microsoft® Windows® XP Professional
-
Microsoft® Windows® 2003
MATLAB® :
-
R13 or higher with Data Acquisition Toolbox 2.2 or higher
Hardware Support
-
NuDAQ PCI/cPCI Series
6208, 6216, 6308, 7200, 7224, 7230, 7233, 7234, 7248, 7250, 7256, 7258, 7260, 7296, 7300, 7348, 7396, 7432, 7433, 7434, 7442, 7452, 9111, 9112, 9113, 9114, 9118, 9810, 9812, 9820 -
DAQ-2000/ PXI-2000 Series
2005, 2006, 2010, 2016, 2204, 2205, 2206, 2208, 2213, 2214, 2501, 2502
